Hub centric rings GETMANN 72.6 x 66.6 GR4-726.666.4823 buy in the online store ADAPTEX-SHOP.EU
Fits to:
AUDI ▾
A4 (2007-2022), A4 AllRoad (2007-2022), A5 (2007-2022), A6 (2011-2022), A7, A8 (2010-2022), Q5, Q7 (2015-2022), Q8, RS4 (2012-2022), RS5 (2010-2022), RS6 (2013-2022), RS7, S4 (2009-2022), S5 (2007-2022), S6 (2011-2022), S7, S8, SQ5, SQ7 (2016-2022), SQ8, RSQ5, RSQ7 (2016-2022), RSQ8
BMW ▾
1 Series (F52), 2 Series (G42,F45, U06), 3 Series (G20, G21), 4 Series (G22/G23/G26), 5 Series (G30, G31), 6 Series (G32), 7 Series (G11, G12), i3, i8, X1 (F48), X2 (F39), X3 (G01), X4 (G02), X5 (G05), X6 (G06), X7, Z4 (G29)
MINI ▾
Cooper (F55, F56), Clubman (F54), Countryman (F60), One (F55), Convertible (F57)
MERCEDES ▾
A-Class (W168, W169, W176, W177), B-Class (W245, W246, W247), C-Class (W202, W203, W204, W205, W206), CL-Class (C140, C215, C216), CLA-Class (C117, C118), CLS-Class (C218, C257), E-Class (W124, W210, W211, W212, W213, W238, W207)
Characteristics
Amount per set: 4 pcs.
Dimensions:
- 1 - Outer diameter (mm): Ø 72.6
- 2 - Inner diameter (mm): Ø 66,6
- L - Ring height (mm): 10
- Material: thermoplastic
Depending on delivery, the rings may differ in colour.
The need for centring rings arises when fitting rims whose central bore does not match the vehicle hub.
The main function of the centring rings is to eliminate the void between the centring hole of the rim and the hub. If this space is not eliminated, there is a risk of wheel vibration, vibration of the steering wheel, which causes increased wear on the steering and suspension components of the car. These problems most often occur at speeds of 90-120 km/h.
How do I size the rings?
For the correct self-selection of the centring rings, we need to check 2 parameters:
1 - The diameter of the rim's central hole (which will correspond to the outer diameter of the ring)
2 - Hub diameter (which will correspond to the inner diameter of the ring)
The diameter of the centre hole of the rim can be consulted in the manufacturer's specifications and the diameter of the hub can be consulted in the vehicle documentation.
If you have difficulty finding these parameters, please contact us - we will help you professionally select the correct centring rings.
Description
The 72.6 x 66.6 centring rings are made of heat-resistant polycarbonate with exact dimensions.
Centring rings made of heat-resistant polycarbonate will not stick to the hub, stand out for their hardness and resistance to cracking even under the most dynamic loads. Thanks to this material and dimensional accuracy, GETMANN centring rings withstand a large number of wheel assembly and disassembly procedures and do not differ in service life from more expensive metal counterparts.
The strict dimensions of these rings ensure precise centring on the vehicle wheel hub and prevent the problem of wheel run-out after replacing standard rims.
- Quantity
- 4 szt.
- Outer Diameter – Rim (mm)
- 72,6
- Inner Diameter – Hub (mm)
- 66,6
- Manufacturer
- Getmann
- Category
- Hub Centering Rings
- Stan
- Nowy
- Typ samochodu
- Samochody osobowe
- Kod producenta
- GR4-726.666.4823
