Wheel Spacers 22MM 5x112 66.6 M14x1.5 MERCEDES 22WSF.FA6-B.7558 buy in the online store ADAPTEX-SHOP.EU
Spacers require careful selection. Please read the offer carefully.
Characteristics
Quantity in set: 2 pcs.
Special screws included: 10 pcs.
Spacer type: with sleeves
- A – Bolt spacing (PCD): 5x112
- F – Sleeve: M14 x 1.5
- ⌀ – Outer diameter: 150 mm
- S – Thickness (mm): 22
- D₁ – Outer diameter (mm): 66.6
- D₂ – Inner diameter (mm): 66.6
- Colour: matt black
- Material: aluminium
Manufacturer: GETMANN
Note: Please indicate the model and year of manufacture of your car in the comments section of your order. This will allow us to additionally check whether the selected spacers and bolts will fit.
Spacers with sleeves (so-called bolt-on spacers) are designed in such a way that the spacer is attached to the car hub with special bolts, and the rim is attached to the spacer surface with standard bolts that are screwed into special steel sleeves. The special bolts and sleeves in the spacers have identical threads to standard bolts and the thread in the car hub. This allows for installation without replacing standard fasteners.
Spacers of this type reduce the load on the fasteners, as there are 10 bolts instead of 5, which is an important advantage when installing spacers in heavy vehicles and cars with powerful engines. In addition, GETMANN bolt-on spacers have a centring flange for convenient installation and perfect balancing of all structural elements.
Installation diagram for bolt-on spacers (with sleeves)
The spacer ② is clamped between the car hub ① and the rim ③ using special bolts ④, which are included in the set. The rim is attached to the spacer using standard bolts ⑤.
List of vehicles compatible with the installation of 22MM 5x112 66.6 M14x1.5 bolt-on spacers:
MERCEDES-BENZ▾
GLA H247 (2020 - )
GLB X247 (2019 - )
GLC X253, C253, C254 (2016 - )
C-Class W206 (2021 - )
CLA C118 (2019 - )
CLS C218 (2010 - 2018) – rear axle only
The list assumes that the spacers will be mounted on the original (standard) alloy wheels. If the spacers are to be mounted on non-standard wheels for this car, individual selection of spacer parameters is required.
Due to the many unique configurations of vehicles and rims, this list cannot be 100% complete. Therefore, please ensure that the spacers and fasteners fit your car and rim configuration. Installation instructions are included in the kit.
If you have difficulty finding the right parameters, please contact us – we will help you professionally select the spacers that fit your car.
DESCRIPTION
GETMANN wheel spacers are used to widen the wheelbase of a vehicle. By installing GETMANN spacers, you will achieve a more dynamic look for your vehicle and better control when driving.
GETMANN wheel spacers are manufactured from high-strength aluminium alloy with tight manufacturing tolerances on state-of-the-art CNC machines, ensuring exceptional wheel balance. A special anodised coating makes them more resistant to weather conditions and guarantees lasting protection against corrosion and a long service life.
The company's employees have extensive experience gained from carrying out complex tasks in the field of motorsport, in such disciplines as drifting, drag racing, time attack, off-road and others.
The combination of these factors means that GETMANN wheel spacers, when properly selected, will fit your car perfectly.
Regardless of the type of wheel fasteners (bolts or nuts), GETMANN offers suitable spacers for the vast majority of vehicles, which ensure a positive visual effect even when using standard rims.
Spacers are mounted using one of three systems (through-type, with sleeves and with pins). Regardless of the type of spacers installed, we recommend using only certified wheel mounting products.
The spacers are manufactured in accordance with international standards, including fasteners certified to UNI EN ISO 9001:2015. Full control over the production line guarantees exceptional attention to detail at all stages of production.
In our shop, you will find only high-quality products that meet all the quality standards necessary for the installation of spacers, which guarantees the safe operation of your car.
- Quantity
- 2 szt.
- Manufacturer
- GETMANN
- Category
- Wheel Spacers
- Thickness of a Single Spacer
- 22
- Color
- Czarny
- Center Bore (mm)
- 66,6
- PCD
- 5x112
- Outer Diameter
- 150
- Kod Producenta
- 22WSF.FA6-B.7558
- Stan
- Nowy
- Typ samochodu
- Samochody Osobowe
- Informacje dodatkowe
- śruby w zestawie
